Bridge Table Form

System Description :

ACROW Bridge Deck Table Form is an ideal system for different bridge sections and loads. All elements and accessories are assembled only once on site and then freely moved from one location to another utilizing a tower crane, forklift, or truck.

System Application :

Bridges System
Bridge decks of both uniform & variable sections (depth and width).
Underpasses and flyovers.
Viaducts.

Features :

Heavy Duty

Highly compatible

Highly Worked

Time saver

Features:

Lowering devices: for table lowering after concrete maturity.
Transportation wheel-jack unit: for shoring towers movement & reallocation.
Tailored curved splice: for curved soffit, web, and top slab-web connections.
Adjustable pivot splice: For side shutter adjustment (retraction & rotation)-in case of variable depth bridges.
C-Fork: The side shutters can release first and reallocation in other casting segments.

System Main Components :

Soldier
H20 timber
Connection and tilting props.
Shoring & adjustable jacks.
Transportation jack unit (for shoring)
Lowering device
Tie Rods

Technical Data :

Table standard lengths: 2.5 & 3m (can be designed according to bridge design).
Standard shoring: Shore-brace frames and ACROW Z-frames.
Alternative shoring types: Ring lock.
